P. 40

ELE    C TRICAL          A CCE    SSORIE        S   -   RELA   Y  S   &   B ASE    S
       ELECTRICAL ACCESSORIES - RELAYS & BASES

        Mini Relays                                             European Type Mini Relays

       • Highest quality contacts                               • Plated copper terminals
       • Resistor protected                                     • Resistor protected
       • Plated copper terminals                                • 4 and 5 Pin Models
       • Larger mounting hole
       • Removable bracket
       • Epoxy sealed                                            Model    Type    Voltage Amps Pins Info/Price
                                                                 RE12-1A N/Open 12       40    4
        Model   Type    Voltage Amps Pins   Info/Price           RE12-1C C/Over   12     40/30 5
        R12-2A N/Open 12        50     5
        R12-1C C/Over   12      50/30  5
        R24-2A N/Open 24        30     5                        Heavy Duty Relays
        R24-1C C/Over   24      30/20  5
                                                                • Plated copper terminals
                                                                • Larger 30 & 87 terminals
                                                                • Large contacts
        Micro Relays                                            • Removable steel bracket

       • Plated copper terminals                                • Resistor protected
       • Resistor protected
       • Epoxy sealed                                            Model    Type    Voltage Amps Pins Info/Price

                                                                 RH12-1A N/Open 12        80    4
                                                                 RH24-1A N/Open 24        50    4
        Model     Type    Voltage Amps Pins Info/Price
        RM12-1A N/Open 12        25     4
        RM12-1C C/Over    12     25/20  5                       Japanese Type Mini Relays
        RM24-1A N/Open 24        15     4
                                                                • 30 Amp contact
        RM24-1C C/Over    24     15/10  5
                                                                • Epoxy sealed

       Relay Base
       • Suit mini relays                                       Model     Type    Voltage  Amps Pins Info/Price
       • Interlockable                                          R-387-12 N/Open 12        30     4

        Model   Info/Price
        RB-2
                                                                Relay Base
                                                                • Suit H/Duty relays
                                                                • Interlockable
       Relay Base
       • Suit micro relays                                       Model   Info/Price
       • Interlockable
                                                                 RB-6
        Model   Info/Price
        RB-5



       ELE   C  TRICAL         A CCE   SSORIE        S   -   DIODE    S   &   BRIDGE         RE  C TIFIER      S
       ELECTRICAL ACCESSORIES - DIODES & BRIDGE RECTIFIERS

       Diodes                                                   BRIDGE RECTIFIER

        Model Voltage Rating    Pack Info/Price                  Model Voltage Rating   Info/Price
        D-1    1000     1AMP    10                               BR-37 1000     50AMP
        D-3    1000     3AMP    10
        D-6    1000     6AMP    10



      38                     Electro Parts Australia Pty Ltd  -  www.electroparts.com.au  -  1300 10 60 10
