SOLAR CHARGE CONTROLLER: PWM
SOLAR CHAR GE C ONTR OLLER : PWM

P2440N - (12V/24V - 40)

• Use as Solar Controller and Battery Protector
• 40A PWM Switching • 40A Output load terminals with LVD
• 12/24V with auto battery detect • In-built Bluetooth for smart phone APP
• LCD display & key operation • Suits Flooded/AGM/GEL/Lithium batteries
• Pre-set & User adjustable charging voltages • Multiple DC load output controls available
• Over-charge, Over-discharge, Short-circuit • USB Outlet - 5V/1Amp
Reverse polarity, Over-heat & Over-load protection • 24 Month Warranty

Model P2440N
Max PV Voltage (VoC) <55V
Max PV Watts 600W/12V | 1200W/24V
Maximum Input/Load Current 40A
No Load Current 8mA/12V | 12mA 24V
Battery Voltage/Type (Auto detect) 12V/24V - STD/AGM/GEL/LI/USER
Float Voltage 12V/24V 13.8V / 27.6V
Bulk Voltage 12v STD:14.6V / AGM: 14.4V / GEL: 14.2V / LI:14.2V
Bulk Voltage 24v STD:29.2V / AGM: 28.8V / GEL: 28.4V / LI:28.4V
Low Voltage Disconnect/Reconnect 12V/24V 11.1V/22.2V - 12.6V / 25.2V
LxWxH (mm) - Weight 159x118x59 - 0.65Kg
Info/Price

SOLAR CHARGE CONTROLLERS: MPPT

SCL-1550L - (12V - 15A)
Model SCL-1550L
• Innovative Full Digital MPPT technology System Voltage 12V
• Preprogrammed for Lithium (LiFePO4) type batteries Maximum Input Current 15A
• Also suitable for AGM/Sealed Batteries
• IP67, Strong and durable aluminum case Max PV Voltage (VoC) <35V
• Full automatic electronic protect function Battery Type Lithium (LiFePO4)
Charging Voltage Recovery/Target 13.5V/14.4V
Max Recommended Input (Watts) 220W
Bulk Voltage 14.4V
Low Voltage Disconnect/Reconnect 11.1V / 12.5V
Operating Temperature -35 deg - +60deg C
LxWxH (mm) 86x81x23 - 0.26Kg
