Page 25 - Catalogue-EP-July-2024

DC - DC CHAR GER
DC-DC CHARGER

SDC-1120 Model SDC-1120
12V/12V - 20A
Current Output 20A
Input Voltage 9 - 16V DC

Output Voltage (adjustable) 13.2 - 14.8V
LxWxH (mm) - Weight 184x115x70 - 1.4kg
Info/Price

• Charges GEL, WET & AGM batteries • 4 Stage battery charging • Input/ Output isolated
• Switch mode high efficiency • No Radio interference • Cooling fan
• Short circuit & over temp protection • Ignition trigger input • 12 Month Warranty
DC TO DC CONVERTER/CHARGER 24V-12V
DC T O DC C ONVER TER / CHAR GER 2 4 V - 1 2 V

VC-30
VC-40
Model VC-30
Input Voltage 19-36V DC
Output Current 30A 40A
Preset Output Voltage 13.8V DC
Adj. Output Range 12-15V DC
Memory Output 12V 0.5A
Efficiency >90%
Approvals CE: EN 55022
LxWxH (mm) - Weight 190x130x57 - 1Kg 210x130x57 - 1.1Kg
Info/Price

• 19-36V DC Input • LED Volts/Amps display • 2 Stage charging
• Adjustable output (12-15V) • Memory output (12V 0.5A) • Ignition trigger
• Protections with fault codes • Fused input & output • 24 Month warranty
• Use as Convertor or battery charge
• Auto recovery from:- Input under Voltage - Output over Voltage - Output short circuit - Output overload - Over temperature

DC T O DC C ONVER TER / E QU ALIZER / CHAR GER 2 4 V - 1 2 V
DC TO DC CONVERTER / EQUALIZER / CHARGER 24V-12V

BBC-3140
Select from 24-12VDC Converter / 24V Battery • 40Amp Output • 4 Stage Battery Charging
Bank Equalizer or 24-12VDC Battery • Ignition trigger • Overload protection
Charger modes. • Over Voltage Protection • Reverse Polarity Protection
• Adj. Regulated Output • No radio interference
• Cooling fan • 12 Month warranty
• 290x156x60mm - 2.3Kg

BBR-3100
Optional Remote Control/
Display with 10m cable.
LxWxH -115 x 60 x 15mm

Model BBC-3140 BBR-3100
Info/Price

Electro Parts Australia Pty Ltd - www.electroparts.com.au - 1300 10 60 10 23
