DC-DC CHARGER & MPPT SOLAR CONTROLLERS
DC
-
T

SOLAR
MPP

&

OLLER

C
ONTR
S
DCS-1240 The DCS-1240 is Dual Input DC to DC charger is suitable for charging all
Input - 12V/24V + PV common types of automotive or recreational lead acid & LiFePO4 Lithium
Output - 12V/40A 12v batteries. The charger can operate on 12 or 24 volts altenators (inc. Smart
Altenators) and 12v nominal solar input. In-built Low-Voltage, Over-Voltage,
Over-Temperature and Reverse Polarity Protection.
Model DCS-1240
DC Input 11.5-32V
PV Input (VOC) 9-32V - 500W Max
Output Current 40A
Rec. Battery Capacity 120-400Ah
Standby Current <10mA
Opperating Temp. -20 °C to 80°C
Charger Type 3 Stage
Charge Voltage Absorption Float
Lead Acid 14.4V 13.6V
GEL/AGM 14.1V 13.6V

CALCIUM 15.3V 13.6V
LiFePO4 14.4V
Includes 3 x 50A IP Rating IP68
Connectors
LxWH (mm) - Weight 190x130x40 - 1.3Kg
Info/Price

SCM030 The SCM030 is designed to fully charge AUX batteries using either the
12V/12V - 30A vehicles power (DC to DC booster) or solar panel (MPPT) sources. It will
24V/12V - 30A automatically detect when power is available and begin charging. Either
input can be set as the “priority source” Charging voltages can be adjusted
to suit different battery types including LiFePO4.

Model SCM030
_
DC Input 8-50V
PV Input (VOC) 10-50V 500W Max
Charge Voltage 14-15V Adj
Float Voltage 13.2-13.8V Adj

• 8-50V DC Input Output Current 30A
• 10-50V PV Solar input Standby Current <60mA
• 500W Solar input
• Auto detects input source Sleep mode Current <20mA
• Multi window LCD display Min Batt Volt 8V
• Programmable charge voltages
• Input source priority select Min DC Input V 8-26V Adj
• Programmable LVD connect voltages DC Input Recon V 8.5-34V Adj
• Can charge 12V batteries from 24V solar LxWH (mm) - Weight 240x205x88 - 1.9Kg
• Fan cooled (auto) for true 30A output
• Optional battery temperature sensor - TS-10 Info/Price
• 24 Month Warranty

TS-10 Model Cable Suits Info/Price
Optional Temp Sensor TS-10 3M SCM030
