Page 26 - Catalogue-EP-July-2024

TER

3
ONVER
DC

C

CHAR

GER
/
6
V

-
O
2
V
DC
DC TO DC CONVERTER / CHARGER 36V - 12V

T

1
IPC-3120
• Can charge batteries (@13.8V) • Parallel for more output
• Ignition trigger • No radio interference
• Input/Output isolated • Over load protection
• Short circuit protection • Over temp protection
• Fan cooled • 12 Month warranty
Model Output Current Output Voltage LxWxH (mm) - Weight Info/Price
IPC-3120 20A 36V - 12V 195x115x80 - 1.14Kg
DC T O DC C ONVER TER / CHAR GER 4 8 V - 1 2 V
DC TO DC CONVERTER/CHARGER 48V - 12V
VC-4820
• Use as converter or charger • 2 Stage battery charging • LED Volts/Amps display
• Fault, mode and charge display • Ignition trigger • Adjustable output
• Most protections auto recover • Input & output fused • Memory O/P Cut (12V/5A)
• 24 Month Warranty

Model VC-4820
Input Voltage 36-60V DC
Output Current 20A
Preset Output Voltage 13.8V DC
Adj. Output Range 12-15V DC
Memory Output 12V 0.5A
Efficiency >90%
Approvals EN 55022, EN 60335 2.29
Standby Current <60mA
LxWxH (mm) - Weight 210x130x57 - 1.05Kg
Info/Price

BATTERY PROTECTORS
B A T TER Y PR O TE C T OR S

• Stop batteries from being over discharged
• Switches load on/off automatically
• Optional remote on/off feature
• Can also operate as a master switch for 12V circuits
• Used by many caravan OEMs
• 24 Month Warranty

Model Input A Input V Off Voltage (LVD) On Voltage LxWxH (mm) - Weight Info/Price
BP-400 40A 12V 10V, 10.5, 11V, & 12V LVD + 1V 85x70x35 - 0.4Kg
LxWxH with bracket = 112 x 70 x 35mm

24 Electro Parts Australia Pty Ltd - www.electroparts.com.au - 1300 10 60 10
