Page 12 - Catalogue-EP-July-2024

SOLAR CHARGE CONTROLLERS: MPPT

SCL-1550L - (12V - 15A)

• Innovative MPPT technology Model SCL-1550L
• Full digital technology, high charge conversion up to 97.5%
• Preprogrammed for Lithium (LiFePO4) type batteries System Voltage 12V
• Also suitable for AGM/Sealed Batteries Maximum Input Current 15A
• IP67, Strong and durable aluminum case Max PV Voltage (VoC) <35V
• Full automatic electronic protect function Battery Type Lithium (LiFePO4)
Charging Voltage target 14.4V
Charging Voltage recovery 13.5V
Max Input power (Watts) 200W
Bulk Voltage 14.4V
Low Voltage Reconnect 12.5V
Low Voltage Disconnect 11V
Max charge conversion 97.5%
Operating Temperature -35 deg - +60deg C
IP Rating IP67
LxWxH (mm) 86x81x23 - 0.26Kg
Info/Price

PRO SERIES PURE SINE WAVE INVERTER

• Pure Sine Wave <2.5%
• Built for 24 hr. operation
• Power saving mode (Eco) <1W
• Turbo mode: 120% continuous output
power when temp <30° C
• Single AC outlets (700W & 1000W models)
• Dual AC outlets (1500W & 2000W models)
• Single AC outlet & hard wire option 3000W
models
• Output voltage 230V AC 50Hz
• DC under input & over voltage protection
• Short circuit & overload protection
• Reverse polarity protection
• Over temperature protection
• 24 Month Warranty
• Optional Remote/Control Display

Optional Remote Control/Display

Model Cable LxWxH (mm) Info/Price
TRN-100 8M 110x60x35
TRC-100 8M 167x94x35

12v Model 24v Model Remote AC Outlet Cont. Pwr Surge Pwr LxWxH Kg Info/Price
PS700-12 PS700-24 Optional 1 700W 1400W 240x222x89 2.9
PS1000-12 PS1000-24 Optional 1 1000W 2000W 280x222x89 3.6
PS1500-12 PS1500-24 Optional 2 1500W 3000W 340x222x89 4.3
PS2000-12 PS2000-24 Optional 2 2000W 4000W 405x222x98 5.8
PS3000-12 PS3000-24 Optional 1 + hardwire 3000W 6000W 490x222x89 6.8
PS3000-12 & PS3000-24 models include 1 x 230Vac outlet and hard wire option.

10 Electro Parts Australia Pty Ltd - www.electroparts.com.au - 1300 10 60 10
