SOLAR ACCESSORIES
SOLAR A CCE SSORIE S

Solar Connectors
Max. rated current 30A

MC4 MC4-2A MC4-3A MC4-4A MC4-2CA

Model Qty Description Info/Price
MC4 1 pair Connector
MC4-10 10 pair Connector
MC4-2A 1 pair 2 Way Y Adaptor
MC4-3A 1 pair 3 Way Adaptor
MC4-4A 1 pair 4 Way Adaptor
MC4-2CA 1 pair 2 Way Cable Adaptor
MC4-3CA 1 pair 3 Way Cable Adaptor
MC4-3CA MC4-4CA MC4-4CA 1 pair 4 Way Cable Adaptor

MC4-FH10
MC4-FH15 Model MC4-FH10 MC4-FH15
MC4 Solar Panel Fuse Holder & Fuse Contacts material: Copper
Insulator Material: PC
Maximum working voltage: DC1000V
Fuse Current: 10A 15A
Flame class: UL94-V0
Contact resistance: ≤ 5mm Ω
Shell Protection degree: IP65
Spec. of Connecting Line: 1.5~6mm2
Ambient temperature range: -40 to +85 °C
Safety Level: Class II
Info/Price

SOLAR CHARGE CONTROLLERS
SOLAR CHAR GE C ONTR OLLER S

IR220 - (12V/24V - 20A - PWM) Model IR220
System Voltage 12V/24V
Max PV Panel VOC 41V
Max PV Panel ISC 20A
Charging Current 20A
Min Operating Voltage 6V
Charging Voltage - Absorption 14.3V / 28.6V
Charging Voltage - Float 13.8V / 27.6V
Low Voltage Disconnect 11.5V / 23V
• Sealed (IP 68) Low Voltage Reconnect 12.6V / 25.2V
• LED Indicators LxWxH (mm) - Weight 82x45x20 - 0.12Kg
• Auto Batt. V Detect • 24 Month Warranty Info/Price
