Page 5 - Catalogue-EP-2022
P. 5
ANELS
SOLAR
P
LIGHTWEIGHT SOLAR PANELS
LIGHTWEIGHT
Voltech IBC Lightweight Solar Panels combine a unique, patented polymer
material with industry-leading technologies to produce a flexible
monocrystalline panel that can be installed on a curved surfaces.
• IBC-No electrode to block sunlight
• Monocrystalline cells
• 70% lighter than glass panels
• N-Type cell has Zero LID
• Load tested to 2400 Pascals
• IP68 Rated
• MC4 Connectors
• 5 Year warranty
Model - 12V Edge Style Pwr Vmp Imp Voc Isc LxWxH (mm) Weight Price
SF-185 Frameless 185W 18.8V 9.85A 22.1V 10.54A 1396x700x3 3kg
All ratings are +/- 5%
OLD
BLANKET
SOLAR
ABLE
F
FOLDABLE SOLAR BLANKET
Voltech foldable solar blankets offer high performance charging, strength and portability. Available in 120W,
160W & 200W that come with all the accessories needed to quickly set up a portable charging system.
Voltech foldable solar blanket kit features -
• Monocrystalline cells • Light weight & compact
• 120W, 160W & 200W sizes available • Available with or without legs
• IP68 - 12V Charge controller included • 50A Grey Anderson style connectors
• 24 Month warranty
FSB-120 FSB-160 FSB-200
FSB-120L FSB-160L FSB-200L All ratings are +/- 3%
Model Pwr Vmp Imp Voc Isc Controller Legs LWH Closed (mm) LWH Open (mm) Weight Info/Price
FSB-120 120W 18.1V 6.67A 21.24V 7.33A 20A No 370x380x80 1100x730x10 4.5kg
FSB-120L 120W 18.1V 6.67A 21.24V 7.33A 20A Yes 450x520x50 1820x520x10 5.9kg
FSB-160 160W 19.8V 8.08A 21.24V 8.89A 20A No 360x480x80 1100x940x10 5.5kg
FSB-160L 160W 19.8V 8.08A 21.24V 8.89A 20A Yes 430x540x80 2195x540x10 7.1kg
FSB-200 200W 18.1V 11.05A 21.24V 12.31A 20A No 420x470x80 1260x950x10 5.8kg
FSB-200L 200W 18.1V 11.05A 21.24V 12.31A 20A Yes 570x590x80 2890x590x10 9.3kg
Electro Parts Australia Pty Ltd - www.electroparts.com.au - 1300 10 60 10 3
