LIGHT WEIGHT SOLAR PANELS
       LIGHT          WEIGHT              SOLAR           P  ANELS


       75% LIGHTER - 85% THINNER - 100% IMPROVEMENT


       eArc is a light weight and ultra-thin solar panel made with a fibreglass reinforced composite material similar
       to aircraft windows, and 75% lighter than conventional solar panels, making it far less costly to transport and
       install.  eArc light weight solar panels are ideal for caravans, motorhomes, RV’s, Buses, 4WDs, boats, yachts
       and even trains.  Yes trains, in fact the eArc panels are used on the world’s first solar powered train in our
       own Byron Bay, NSW.

       eArc  solar panels are also the first light weight solar panel approved for off grid use by the Clean
       Energy Council of Australia, meeting the same durability tests that conventional glass solar panels must
       (IEC61215:2016) as inuse on many home and commercial applications in Australia including the Sydney
       Maritime Museum Heritage Building.

       • Ultra-light - eArc weighs around 75% less than conventional PV panels.  Panels measure just 2mm with
         a 100watt panel weighing just 2.1kgs.
       • Flexible - eArc combines a unique, patented material to produce a superior flexible crystalline-silicon/
         panel  which can be installed on curved surfaces.
       • Easy Installation - eArc can reduce installation cost through ease of handling and faster installation.
         Without the added cost of mounting hardware.
       • Durability - eArc panels are certified to withstand maximum test load (2400 Pascal) and hail tested with
         200g/35mm diameter ice stones at 39.5m per second.
       • Warranty - 5 Year Warranty






































        Model - 12V          Edge Style Pwr     Vmp    Imp      Voc    Isc      LxWxH (mm)     Weight Info/Price

        SMF100F-3X12UW       Frameless   100W 21.2V 4.75A       25.2V 5.12A     1093x582x2     2.1kg
        SMF175M-4X09UW       Frameless   175W 19.5V 8.98A       23.9V 9.50A     1504x673x2     3.0kg
        SMF190F-4X16UW       Frameless   190W 18.6V 10.22A      22.1V 10.72A    1438x710x2     3.25kg
        SMF215F-4X18UW       Frameless   215W 21.0V 10.24A      24.9V 10.72A    1610X710X2     3.8kg

        Model - 24V          Edge Style Pwr     Vmp    Imp      Voc    Isc     LxWxH (mm)      Weight Info/Price
        SMF430F-12X12UW      Frameless   430W 42V      10.24A   49.8V 10.74A 2054x1093x2       7.3kg

                                                                                                All ratings are +/- 5%
