SOLAR CHARGE CONTROLLERS: MPPT

MPPT technology helps to extract up to 30% more power out of same solar panels. This technology will enable
your batteries to be charged faster with fewer solar panels. They also have the ability to charge 12V batteries from
12V or 24V solar panels.

SCP030 - (12V /24V - 30A) • MPPT Solar Controller
SCP050 - ({12V/24V - 50A) • 12/24/36/48V Auto Select
• 30Amp or 50Amp models available
• PV: SCP030 (500W - 12V) - (1000W - 24V)
• PV: SCP050 (700W@12V) - (1400W - 24/36/48V)
• PV Input VoC: SCP030 - 100V - SCP050 - 135V
• Backlit LCD display
• 2 x USB Outlets
• Monitor System via Smart Phone App
• Preset battery types including LiFePO4
• Optional battery temperture sensor - TS-10
• 24 Month warranty

Optional Temp Sensor
Model Cable Info/Price
TS-10 3M

Technical Info SCP030 SCP050
Max. PV Power @ 12V/24V 500W 1000W 700W 1400W
Max. PV Power @ 36V/48V - 1400W 1400W
PV MPPT Voltage Range @ 12V/24V 16 - 80VDC 32 - 80VDC 16 - 80VDC 32 - 80VDC
PV Input
PV MPPT Voltage Range @ 36V/48V - 48 - 108VDC 64 - 108VDC
PV VoC Max. 100VDC 135VDC
MPPT efficiency ≥ 99%
Battery Voltage/Type (Auto detect) 12V - STD/
AGM/LiFePO4 24V/36V/48V - STD/AGM
Max. Charging Current 30A 50A
Battery
Max. Charging Voltage STD: 14.4V/28.8V STD: 14.4V/28.8V/43.2V/57.6V
AGM: 14.6V/29.2V AGM: 14.6V/29.2V/43.8V/58.4V
LiFePO4: 14.5V/29V LiFePO4: 14.5V/29V
Max. Load Current 30A 50A
Low Battery Protection (Programmable) 12V/24V 10V~11.5V 20V~23V 10V~11.5V 20V~23V
Low Battery Recover (Programmable) 12V/24V 12V~13V 24V~26V 12V~13V 24V~26V
DC Low Battery Protection (Programmable) 36V/48V - 30V-34.5V 40V-46V
Load &
Output Low Battery Recover (Programmable) 36V/48V - 36V-39V 48V-52V
USB Output Voltage - Single Output Current 5V - 3A
Total Output Current for 2 USB 3.4A
USB Low Battery Protection/ Recover Voltage 10.5V - 11.0V
Standby Current (WiFi Off/On Mode) ≤60mA - ≤160mA
Operating Temperature Range -10°C/+50°C
Dimensions (LxWxH) - Weight 238x177x63mm - 1.5kg 238x177x73mm - 2.3kg
Info/Price
