SOLAR CHARGE CONTROLLERS: MPPT

SCW15M / SCW30M / SCW50M / SCW70M
• MPPT Solar Controller
• 12/24 V Auto Select and 48V on SCW70M SCW15M
• 15/30/50/70Amp Output Models available
• 30/50/70Amp Models with Lithium preset
• PV Input Volts up to 150V
• Intelligent battery management
• Graphical LCD display
• Simple menu-driven operation
• Output load terminals with LVD (SCW15M)
• 24 Month Warranty

SCW30M
SCW50M SCW70M

Model SCW15M SCW30M SCW50M SCW70M
Battery voltage 12/24 V Auto Select 12/24/48 V Auto Select
Maximum battery current 15A 30A 50A 70A
Maximum PV power, 12V 1a,b) 200W 440W 720W 1000W
Maximum PV power, 24V 1a,b) 400W 880W 1440W 2000W
Maximum PV power, 48V 1a,b) N/A 4000W
Automatic load disconnect Yes, max. load 15A N/A
Maximum PV open circuit voltage 100V 150V
Peak ef ficiency 98%
Self consumption 20mA <35mA @ 12V/ 20mA @ 48V
Charge voltage ‘absorption‘ Default setting: 14.4V / 28.8V / 57.6V (adjustable)
Charge voltage ‘equalization‘ N/A Default setting: 16.2V / 32.4V / 64.8V (adjustable)

Charge voltage ‘float‘ Default setting: 13.8V / 27.6V / 55.2V (adjustable)
Temperature compensation -16mV/°C resp. -32mV/°C resp. -64mV/°C
Protection Battery reverse polarity (fuse) Output short circuit / Over temperature
Operating temperature -30 to +60°C (full rated output up to 40°C)
Power terminals 6mm² / AWG10 13mm² / AWG6 35mm² / AWG2
Protection category IP43 (electronic components) / IP22 (connection area)
Dims (HxWxD) mm - Weight kg 136x98x55 - 0.4 186x125x83 - 1.25 186x125x83 - 1.6 248x178x103 - 2.6
Safety EN/IEC 62109
1a) If more PV power is connected, the controller will limit input power to maximum power.
1b) PV voltage must exceed Vbat + 5V for the controller to start. Thereafter minimum PV voltage is Vbat + 1V.
Info/Price

Electro Parts Australia Pty Ltd - www.electroparts.com.au - 1300 10 60 10 9
